Elicottero Ultraleggero

Elicottero CH7

Caratteristiche Salienti

  • Engine
    ROTAX 914 UL- EPA SA-R914
  • Trasmissione
    11.1Two Stage Xmn ,engine 2.61
  • Max Speed (VNE)
    104Kts 120 mph
  • Gross Weight
    450/500 Kg 992/1100 lb
Tecnosoluzioni

Tutte le Caratteristiche

Our ch7 family finds in version Kompress Charlie the exaltation of technology and the realization of the wishes of our customers (and our dreams)

A perfect evolution of that idea, born years before, is made through a helicopter with improved efficiency and autonomy, which grows up to three hours to a convenient removable additional tank, with improved profile, and aerodynamic fairings applied to the landing gear; with improved technology, ranging from information system and language voice check list( in your own language), to renewed mechanical part including a new swash-plate , The retention of the weight is still guaranteed by incuse ok technology, that's to a renewed full carbon cabin.
  • Engine type ROTAX 914 UL- EPA SA-R914
  • Seats 2

Our ch7 family finds in version Kompress Charlie the exaltation of technology and the realization of the wishes of our customers (and our dreams)

A perfect evolution of that idea, born years before, is made through a helicopter with improved efficiency and autonomy, which grows up to three hours to a convenient removable additional tank, with improved profile, and aerodynamic fairings applied to the landing gear; with improved technology, ranging from information system and language voice check list( in your own language), to renewed mechanical part including a new swash-plate , The retention of the weight is still guaranteed by incuse ok technology, that's to a renewed full carbon cabin.
  • Engine type ROTAX 914 UL- EPA SA-R914
  • Seats 2

Dimensions

  • Overall Length 7050 mm 23.1 Ft
  • Overall Height 2350 mm 7.7 Ft
  • Main Rotor diameter 6279 mm 20.5 Ft
  • Standard Fuel capacity 30 lt 7.9 U.S.gal
  • Aux. Fuel capacity 34 lt 8.9 U.S gal

Weights

  • Full load weight 450/500 Kg 992/1100 lb
  • Empty weight 280 Kg 617 lb

Performance

  • VNE 104Kts 120 mph
  • Cruise speed 86 Kts 100 mph
  • Max. Range 259 nm 450km
  • Max. Endurance 3 hours
  • Max. Operating Altitude 15700 ft
  • Hovering IGE (ISA) 9000 ft
  • Hovering OGE (ISA) 7200 ft
  • Rate of Climb 1000 ft/m

Vuoi altre informazioni o desideri provarlo?

Siamo disponibili per qualunque tipo di intervento tecnico, passa a trovarci in sede.
